AB Mares 10 VSX 10’6″ Fiberglass Console Yacht Tender

Description

Review the hull, deck, and propulsion requirements of the AB Inflatables Mares 10 VSX before selecting an outboard. This 3.20 m, or 10 ft 6 in, console yacht tender uses a deep-V double molded fiberglass hull with integrated spray rails. A molded non-skid pattern covers the hand-laid fiberglass deck, while three ORCA CSM 1100 dtex buoyancy tubes use cold-cured hand-laminated seams. Plan lifting and storage around the 175 kg, or 385 lb, net weight.

ISO capacity is four persons, and passenger and cargo planning must remain within the 450 kg, or 992 lb, maximum payload. An integrated 22 L, or 5.8 gal, fuel tank is part of the console configuration. A 15-inch short-shaft outboard is required, with 15 HP recommended, 25 HP maximum, and a 70 kg, or 154 lb, maximum engine weight.

Key Specifications of the AB Inflatables Mares 10 VSX Rigid Inflatable Boat

• The luxury sport-console yacht tender measures 3.20 m, or 10 ft 6 in, overall and has a stated net weight of 175 kg.
• A deep-V double molded fiberglass hull includes integrated spray rails, defining the stated rigid-hull configuration for this console tender.
• Hand-laid fiberglass forms the deck, where a molded non-skid pattern establishes the specified surface configuration for the console layout.
• Three buoyancy tubes use ORCA CSM 1100 dtex fabric with cold-cured hand-laminated seams for the documented tube construction.
• ISO capacity is four persons, and the 450 kg maximum payload sets the stated passenger and cargo limit.
• An integrated 22 L, or 5.8 gal, fuel tank forms part of the specified onboard fuel-storage arrangement.
• A 15-inch short-shaft outboard is required, with 15 HP recommended and 25 HP maximum for engine selection.

Hull, Deck, and Capacity

An internal length of 2.40 m, or 7 ft 10 in, and an internal width of 0.79 m, or 2 ft 7 in, define the stated usable hull space. A 0.41 m, or 16 in, tube diameter accompanies the deep-V fiberglass hull, double molded deck construction, and three buoyancy chambers.

Included equipment consists of a deluxe sport console with steering system, upholstered bow cushion, rear bench seat with storage, integrated fuel tank, LED navigation lights, automatic bilge pump, and stainless steel grab rails. Leafield C7 Push-Push valves serve the tube system, while CE Category C applies to the stated inshore and coastal classification.

Why Choose the AB Inflatables Mares 10 VSX Rigid Inflatable Boat

The Mares 10 VSX rigid inflatable boat combines a 3.20 m fiberglass deep-V hull with double molded construction, integrated spray rails, a 22 L fuel tank, sport console, and three ORCA CSM buoyancy chambers. Its 175 kg net weight, four-person ISO capacity, 450 kg payload rating, short-shaft outboard requirement, 15 HP recommended power, 25 HP maximum power, and 70 kg engine limit provide clear comparison points for a compact console tender.

Setup and Outboard Considerations

The supplied boat includes a sport console with steering, an upholstered bow cushion, rear bench seating with storage, an integrated 22 L fuel tank, LED navigation lights, automatic bilge pump, and stainless steel grab rails. Match the transom with a 15-inch short-shaft outboard, then keep engine output at or below 25 HP and engine weight at or below 70 kg. Inflate the three buoyancy chambers through the Leafield C7 Push-Push valves.

Warranty and Support

AB Inflatables provides a 10-Year Limited Warranty covering ORCA CSM fabric and fiberglass hull structure. Mulmarine.com can help you review the 3.20 m hull dimensions, 175 kg net weight, 22 L fuel-tank arrangement, short-shaft outboard requirement, and stated passenger, payload, and engine limits against your planned tender, lift, trailer, dock, and propulsion setup. Review the stated warranty coverage and documented included equipment before ordering.

Before Ordering the AB Inflatables Mares 10 VSX Rigid Inflatable Boat

Confirm that your lifting, trailer, dock, and storage plan supports the 3.20 m overall length and 175 kg net weight. You should use a 15-inch short-shaft outboard, select 15 HP as the recommended power level, avoid exceeding 25 HP or 70 kg engine weight, confirm the 22 L fuel-tank configuration, and remain within the four-person and 450 kg maximum capacity limits.
