CTM AH-10HN Air Handler / Fan Coil – 10,000 BTU – 230V – NMEA 2000

Description

Boats running NMEA 2000 networks and needing 10,000 BTU of central chiller cooling get MFD-integrated control in the CTM AH-10HN Air Handler, the largest capacity currently reviewed in CTM’s NMEA fan coil lineup with full Garmin Empirbus, OneHelm, and Raymarine YachtSense compatibility.

This nmea 2000 chilled water handler is built to consolidate HVAC monitoring into the boat’s existing network infrastructure — inlet temperature and humidity data flow to the same MFDs already running navigation and other systems, backed by the included Easycool touchscreen for direct local control.

Key Features of the CTM AH-10HN Air Handler

This unit brings NMEA 2000 network integration to CTM’s 10,000 BTU air handler tier, with the same Easycool display and network compatibility found across CTM’s NMEA fan coil range.

• NMEA 2000 connectivity for control through Garmin Empirbus, OneHelm, and Raymarine YachtSense
• Includes Easycool 3.5″ NMEA 2000 touchscreen display (or Easycool Mini 2.4″ with Vimar bezel)
• Bluetooth and Wi-Fi connectivity for remote monitoring via companion Apple or Android apps
• Real-time monitoring of inlet temperature and humidity
• Universal control board compatible with SMXir, Passport I/O, Smart Touch, and Elite II

CTM AH-10HN Technical Specifications

These figures require an especially prominent disclosure: not only does this listing carry the same self-contained/condensing-unit language found on CTM’s other NMEA air handler pages (refrigerant type, seawater connections), but its dimensions and weight are identical to the smaller AH-8HN listing, and the dimension diagram on this page is still labeled “AH-8H Unit Dimensions” — clear evidence this content was copied from the AH-8HN page without being updated for the 10,000 BTU model. None of the figures below should be treated as verified for this specific capacity without direct confirmation from CTM.

• Capacity: 10,000 BTU (as listed; other specs below are unverified — see note above)
• Voltage: 208-240V
• Cycle: 50-60 Hz
• Phase: 1
• Blower Airflow: 350 CFM (identical to AH-8HN listing — unverified for this capacity)
• Blower Speed: 1,200 RPM
• Input Rotor Amps: 0.7 A (identical to AH-8HN listing — unverified for this capacity)
• Fuse Max: 5 A
• Blower Duct Size: 5″
• Dimensions (W x D x H): 16.1″ x 10.7″ x 12.1″ (identical to AH-8HN, with dimension diagram still labeled “AH-8H” — confirm actual AH-10HN dimensions with CTM)
• Net Weight: 22 lbs (identical to AH-8HN listing — unverified for this capacity)

Why Choose the CTM AH-10HN

This unit carries CTM’s standard 2-year warranty against material and workmanship defects. Given the extent of the specification discrepancies identified above — including dimensions that appear to be copy-pasted directly from the AH-8HN listing — confirming every installation-relevant spec with CTM directly before ordering isn’t optional here; the published numbers for this specific model cannot be treated as reliable as published.

What to Know Before Installing

• Do not rely on the dimensions or airflow figures published on this listing — confirm actual AH-10HN specifications directly with CTM given the copy-paste discrepancies noted above
• Requires a matching CTM CW-series chiller as the central cooling source
• If replacing a Dometic AU-HV air handler, waterline connections need adapting from 1/2″ to 3/4″ — adapter included
• NMEA 2000 Starter Kit and temperature/humidity sensor are included with this unit
