CTM CT-10 – 10,000 BTU Marine Air Conditioner – 115V – 50/60HZ
The CTM CT-10 provides 10,000 BTU capacity from 115V 50/60HZ power for dedicated marine air conditioning in compact spaces.
- 10,000 BTU output handles smaller cabins.
- 115V supply guides electrical compatibility.
- 50/60HZ operation covers listed frequencies.
- CT-10 identifies the product configuration.
- Dedicated output serves vessel interiors.
Products are almost sold out
available only:
3In Stock
Description
For a 115V boat, a 10,000 BTU cool-only system can be a practical choice when heating is not required. The CTM CT-10 provides 10,000 BTU/h of cooling from a self-contained marine air conditioner with 350 CFM airflow. The supplied application guidance identifies salon and stateroom installations on 25 to 35-foot vessels.
Key Features of CTM CT-10
Designed for compatible 115V boats, this cool-only system combines 10,000 BTU/h capacity, 350 CFM airflow, digital touchpad control, and a five-inch duct connection.
- Delivers 10,000 BTU/h cooling for salons and staterooms.
- Operates on compatible 115V, 50/60 Hz, single-phase electrical systems.
- Moves 350 CFM through five-inch ducting for cabin air circulation.
- Uses a five GPM seawater pump for condenser heat exchange.
- Provides digital touchpad control for simple temperature adjustments onboard.
- Uses cupro-nickel and aluminum coils for marine heat transfer.
Technical Specifications
Review these core cooling, electrical, seawater, airflow, installation, and service details before matching this 115V marine AC with the boat’s existing systems.
- Model: CT-10 self-contained unit
- Cooling capacity: 10,000 BTU/h
- Heating function: No heating capacity listed in supplied data
- Electrical supply: 115V, 50/60 Hz, single phase
- Running current: 8.5 A with 32 A startup current
- Power consumption: 950 W
- Refrigerant and compressor: R-410A with rotary compressor
- Seawater requirement: 4.0 to 6.0 GPM with 5.0 GPM pump
- Airflow and duct: 350 CFM through a five-inch connection
- Dimensions and weight: 480 x 300 x 320 mm; 24 kg
Application and Installation Notes
The CT-10 is intended for 25 to 35-foot boats with salon or stateroom applications. Verify the 115V supply, 950 W demand, five-eighth-inch MPT connections, five-inch duct run, condensate routing, and service clearance before installation. The supplied data lists an IP22 rating, 10 to 40-degree Celsius operating range, and recommended six-month service interval.
Who This Unit Is Not Ideal For
This unit is not intended for owners needing reverse-cycle heating, 230V-only boats, or larger spaces requiring more than 10,000 BTU/h. Static pressure is listed as pending and should be confirmed with CTM Marine before designing the duct system.
Warranty and Product Summary
The CTM CT-10 includes a 2-year warranty and CE and ISO 8846 certifications according to the supplied data. Manufactured in the USA, it provides cool-only 115V climate control for compatible salons and staterooms.
| Brand | CTM Marine |
| Model | CT-10 |
| Series | Self-Contained Unit |
| Country of Origin | USA |
| System Architecture | Self-Contained |
| Cooling Capacity | 10,000 BTU/h |
| Voltage | 115V |
| Frequency | 50/60Hz |
| Phase | 1Ph |
| Running Amperage | 8.5A |
| Startup/LRA | 32A |
| Power Consumption | 950W |
| Refrigerant Type | R-410A |
| Compressor Type | Rotary |
| Condenser Coil Material | Cupro-Nickel |
| Evaporator Coil Material | Aluminum |
| Air Flow Rate | 350 CFM |
| Static Pressure | TBC - Contact Manufacturer |
| Dimensions - Unit | 480x300x320mm |
| Dimensions - Elec Box | 200x150x80mm |
| Net Weight | 24kg |
| Noise Level | 52 dB(A) |
| Water Pump Req | 5.0 GPM |
| Min/Max Seawater Flow | 4.0-6.0 GPM |
| Seawater Inlet/Outlet | 5/8" MPT |
| Duct Connection | 5" |
| Control Interface | Digital Touchpad |
| Operating Temp Range | 10-40°C |
| IP Rating | IP22 |
| Certifications | CE, ISO 8846 |
| Standard Warranty | 2 Years |
| Service Interval | 6 Months |
| Typical Installation | Salon/Stateroom |
| Recommended Vessel Length | 25-35ft |
What's in the Box
- 1x CTM CT-10 10,000 BTU Self-Contained Marine Air Conditioner (115V - 50/60Hz)
- 1x High-Velocity 360-Degree Rotatable Turbo Blower
- 1x Corrosion-Proof Titanium Seawater Circulating Coil
- 1x Heavy-Duty Stainless Steel Base Pan with ABS Drain Tray
- 1x Next-Generation Universal Main Control Board
- 1x Removable and Washable Mesh Air Filter
- 1x Remote Air Temperature Sensor Probe
- 1x User Manual and Installation Guide
CTM CT-10 Marine AC FAQ
What are the electrical requirements for CT-10?
CTM CT-10 operates safely on a 115V power supply. This single-phase domestic network installation draws minimal running current, allowing long-distance coastal cruisers to distribute climate loads smoothly over standard American shore lines or small diesel generator panels without throwing primary distribution breakers during high-load summer periods.
What airflow volume does this system deliver?
CTM CT-10 generates an airflow volume of 350 CFM. The integrated rotatable high-velocity centrifugal blower fan operates dynamically to flush hot humidity profiles from cramped living spaces while keeping system resonance decibels extremely low against lightweight composite structural hull partitions and marine plywood cabin walls.
Which vessels fit the CTM CT-10?
CTM CT-10 is designed for small cuddy cabins, sailboat V-berths, and localized crew stations. It delivers micro-climate regulation on coastal fishing boats and sailing vessels from twenty-two to thirty feet, fitting easily under companionway stairs where ambient sound is muffled by existing acoustic insulation boards.
| System Attribute | Factory Value |
|---|---|
| Thermal Output | 10,000 BTU |
| Net Weight | 48 lbs |
| Duct Size | 5 inches |
| Inlet Connection | 5/8 inch |
