Raymarine ACU-200 Actuator Control Autopilot Unit
Steering quadrants and hydraulic lines connect directly to the Raymarine ACU-200 course computer, which supplies 15A continuous current to Type 1 drives while powering SeaTalkng networks with up to 3A across 12V or 24V grids.
- 15A continuous output drives Type 1 actuators
- Powers SeaTalkng network buses up to 3A
- Virtual Rudder Feedback eliminates transom sensor rods
- Adaptive 12V/24V circuitry fits various vessels
Products are almost sold out
available only:
7In Stock
Description
The Raymarine ACU-200 Actuator Control Unit, SKU E70099, is a 12V or 24V Evolution autopilot drive controller for compatible Type 1 hydraulic pumps, Type 1 mechanical linear drives, Type 1 rotary drives, and approved geared-motor installations. It supplies the high-current power interface between the EV-1 sensor and control head network and the selected steering drive. The ACU-200 is a component only and requires separate Evolution sensors, controls, drive hardware, and installation materials.
The ACU-200 provides up to 15A continuous drive output and can supply power to the SeaTalkng backbone. Its IPX2 enclosure is intended for dry protected mounting. Verify the selected drive type, motor current, clutch connection, hydraulic-cylinder volume where relevant, 12V or 24V supply, cable size, circuit protection, and steering-system compatibility before purchase.
Key Specifications
- Raymarine Evolution actuator control unit, SKU E70099.
- Supports compatible Type 1 hydraulic pumps, Type 1 mechanical linear drives, Type 1 rotary drives, and approved geared motors.
- Operates from 12V or 24V DC electrical systems.
- Provides up to 15A continuous steering-drive output.
- Connects to compatible Evolution components through SeaTalkng networking.
- Can supply power to the SeaTalkng network backbone within the installed system design.
- Uses an IPX2 drip-resistant enclosure and requires dry internal mounting.
- Requires a separate EV-1 sensor core, p70-series control head, steering drive, power circuit, and complete installation hardware.
System Integration
The ACU-200 is not an autopilot by itself. Pair it with a compatible EV-1 sensor core, p70s or p70Rs control head, SeaTalkng network, and drive unit selected for the vessel’s steering system. Its 15A continuous rating is appropriate for Type 1-class drives, but it is not suitable for a Type 2 or Type 3 drive that requires the higher-capacity ACU-400.
Virtual Rudder Feedback may be supported by the completed Evolution system on suitable vessels, but installations with mechanical steering, linear drives, or specific hydraulic configurations can require a physical rudder-feedback transducer. Verify the required feedback method before system installation.
Installation Considerations
Mount the ACU-200 vertically in a dry accessible location with clearance for power, motor, clutch, and SeaTalkng connections. Use correctly sized marine-grade conductors and circuit protection for the selected actuator, keep high-current wiring away from sensitive network and sensor cables, and verify drive direction and clutch operation during setup. Follow Raymarine dockside and sea-trial procedures after installation.
Before Ordering
Confirm the selected Type 1 hydraulic, linear, rotary, or geared-motor drive, drive current at or below 15A continuous, 12V or 24V supply, EV-1 sensor core, p70-series control head, SeaTalkng network, physical-feedback requirement, dry mounting space, cable sizing, circuit protection, and complete autopilot-system components before purchase.
Raymarine ACU-200 Actuator Control Autopilot Unit
| Brand | Raymarine |
|---|---|
| Full Model SKU/Code | E70099 (ACU-200) |
| Country of Origin | United Kingdom |
| Component Type | Actuator Control Unit (Requires EV-1 Sensor Core and Control Head) |
| Vessel Hull Type Compatibility | Powerboats and Sailboats (Determined by Connected Drive System) |
| Steering System Type Compatibility | Hydraulic, Mechanical, and Rotary Drive Integration |
| Operating Voltage | 12 Volts DC / 24 Volts DC Adaptive Circuit Layer |
| Data Networking Protocols | SeaTalkNG / NMEA 2000 Device Bus Node |
| Drive Unit Compatibility / Output Current | Type 1 Hydraulic Pumps, Mechanical Linear, and Rotary Drives / 15 Amps Continuous Output |
| Waterproof Rating | IPX2 Drip-Resistant Enclosure Structure |
| Maximum Current Draw | Full Actuator Locked Duty Traversal: Max 15 Amps Load Draw |
| Smart Technology Features | Virtual Rudder Feedback (VRF) Processing, Power-On SeaTalkNG Bus Supply Unit (Delivers up to 3 Amps) |
| Dry Weight | 2.2 kg / 4.85 lbs |
| Application | Mid-size outboard center consoles, inboard displacement yachts, and sport cruisers linking to standard Type 1 systems (25-40 ft boat lengths) |
