Simrad AP70 Mk2 Autopilot – Control Head Only

Description

Command a compatible commercial autopilot system with the Simrad AP70 MK2 Autopilot Control Head, a panel, bracket, or desktop-mounted interface with an infinite rotary course-control dial and tactile buttons. The control head connects through dual NMEA 2000 or SimNet ports and supports 12V or 24V DC CAN-bus systems. Its 251 mm by 141 mm profile and 1.3 kg, or 2.8 lb, weight should be accounted for when selecting a helm-console mounting location.

The AP70 MK2 works with compatible AC70, AC80, SG05, and NAC-3 autopilot computers but does not include a processor, steering drive, heading sensor, or complete autopilot system. It draws approximately 0.7A at 12V DC and has an IPX6-rated front panel. A sun cover, gasket, and mounting kit are included, while the control head operates from minus 15°C to 55°C.

Key Specifications of the Simrad AP70 MK2 Autopilot Control Head

• The commercial autopilot control head uses tactile buttons and an infinite rotary dial for compatible course and system commands.
• Dual NMEA 2000 and SimNet ports connect the display through a multi-station CAN-bus network with compatible autopilot computers.
• Operating voltage supports 12V or 24V DC systems, while typical current draw is approximately 0.7A at 12V DC.
• Compatibility includes AC70, AC80, SG05, and NAC-3 autopilot computers, requiring confirmation of the connected course-computer system.
• Panel, bracket, or desktop mounting accommodates a 251 mm by 141 mm controller profile and 1.3 kg chassis weight.
• An IPX6-rated front panel and minus 15°C to 55°C operating range define the stated environmental parameters for the controller.
• The package includes a sun cover, gasket, and mounting kit for the documented control-head installation configuration.

System Integration and Control

This Simrad AP70 MK2 is a control head only. A compatible course computer, steering drive, heading source, network, and vessel-specific autopilot configuration remain separate requirements. The controller supports commercial autopilot applications through the compatible AC70, AC80, SG05, or NAC-3 system architecture.

Confirm the selected display location, NMEA 2000 or SimNet network layout, 12V or 24V power supply, connected processor, and required helm functions before installation. The product information identifies a commercial-grade interface, but system suitability depends on the complete installed steering and navigation system.

Why Choose the Simrad AP70 MK2 Autopilot Control Head

The Simrad AP70 MK2 Autopilot Control Head provides an infinite rotary dial, tactile controls, dual NMEA 2000 and SimNet connections, and 12V or 24V DC support. Its 251 mm by 141 mm format, 1.3 kg chassis, IPX6 front rating, 0.7A typical draw, and compatibility with AC70, AC80, SG05, and NAC-3 computers give buyers defined checks for a multi-station commercial autopilot interface.

Setup and Network Considerations

Confirm that the vessel has a compatible AC70, AC80, SG05, or NAC-3 autopilot computer before selecting this control head. Plan the panel, bracket, or desktop location around the 251 mm by 141 mm profile, cable access, NMEA 2000 or SimNet connections, and 12V or 24V DC supply. Follow Simrad documentation for network wiring, display configuration, and autopilot commissioning.

Warranty and Support

Simrad warranty terms vary by product and region, and the supplied specifications do not provide a named warranty period for the AP70 MK2. Mulmarine.com can help you review control-head mounting requirements, network connections, power supply, course-computer compatibility, and required autopilot components before purchase. Review the applicable Simrad warranty coverage and documented package contents before ordering.

Before Ordering the Simrad AP70 MK2 Autopilot Control Head

Confirm that you need a control head rather than a complete autopilot system and that your vessel has a compatible AC70, AC80, SG05, or NAC-3 computer. You should verify the 251 mm by 141 mm mounting space, 12V or 24V power supply, NMEA 2000 or SimNet network capacity, cable routing, IPX6 front-panel requirement, and required steering-drive and heading-sensor components before purchase.
