Seatronx 15 Sunlight Readable Touch Screen Display

Description

The Seatronx SRT-15 is a high-brightness marine monitor for an exposed helm, radar station, or outdoor charting display. Its 15-inch touchscreen supports 1024 x 768 XGA output and can reach 1000-1500 nits, making it better suited to direct sunlight than an ordinary pilothouse screen. It is a monitor only, so the chartplotter, radar, or computer must be supplied separately.

The SRT-15 accepts VGA, DVI, HDMI, and USB touch input, giving installers several ways to connect an existing source. There is no onboard operating system, sonar, charting, or NMEA interface. The 12-24V DC input fits common marine power systems, while IP67 front-panel protection helps at an exposed station. At 45W maximum, it also needs to be included in the boat’s power budget.

Key Features

• 15-inch sunlight-readable touchscreen – Provides a clear outdoor display for charts, radar, or camera sources.
• 1024 x 768 XGA resolution – Matches the listed source format for compatible computers and electronics.
• 1000-1500 nits brightness – Gives the display more daylight visibility than the pilothouse VPC-15.
• VGA, DVI, HDMI, and USB touch – Accepts several common video and touch connections.
• IP67 front-panel protection – Provides the stated front-face protection for exposed marine mounting.

Who Is This For?

This sunlight-readable marine display suits exposed helms, radar stations, and outdoor charting consoles on larger boats. It is not ideal as a standalone chartplotter or fishfinder, and the supplied information does not list an NMEA interface or built-in marine software.

Compatibility

Confirmed connections include VGA, DVI, HDMI, and USB for touch. The display works with Windows, Linux, and Mac source systems according to the supplied specifications. No specific chartplotter, radar, sonar, NMEA, autopilot, or camera model is identified. No named incompatible system was provided; verify source resolution and touch-driver requirements.

Technical Specifications

• Brand: Seatronx
• Model: SRT-15
• Display: 15-inch sunlight-readable touchscreen
• Resolution: 1024 x 768 XGA
• Brightness: 1000-1500 nits
• Operating system: Independent; compatible with Windows, Linux, and Mac
• Video inputs: VGA, DVI, HDMI
• Touch interface: USB
• Power: 12-24V DC; 45W maximum
• Water rating: IP67 front panel

Warranty & Support

Seatronx provides a 2-year standard warranty. The supplied specifications do not state warranty exclusions or service procedures.

The SRT-15 is the right choice when sunlight readability matters more than built-in navigation features. It offers considerably higher brightness and stronger front-panel protection than the VPC-15, but it remains only a monitor. Choose it for a bright external chart or radar screen; choose a full MFD when you need GPS, mapping, sonar, and marine networking in one unit.
