LA MARCHE – MSM Smart High Frequency Switchmode Charger – 24v – 35A

Description

High-frequency switchmode charging gives theLa Marche MSM 24V/35A Smart Chargera stated 35-amp 24V DC output for workboats, industrial marine systems, and emergency power. Its auto-sensing 102V to 264V AC input supports listed VRLA, AGM, and gel lead-acid battery types through one expandable bank.

A digital display allows the listed customization of absorption and float values, while LCD indications and alarm contacts provide documented local monitoring connections. NEMA 1 identifies this unit for indoor or dry use, and forced-air cooling supports its 85 percent switchmode efficiency. The charger is not ignition protected.

Key Specifications of the La Marche MSM 24V/35A Smart Charger

• Thirty-five-amp output supports the listed 24V workboat charging role.
• One expandable bank supports future listed system expansion.
• Auto-sensing 102V to 264V input supports compatible AC power sources.
• VRLA, AGM, and gel profiles cover listed lead-acid batteries.
• Switchmode architecture provides the listed high-frequency charging method.
• A digital display supports listed absorption and float customization.
• LCD indications provide local charger status information.
• Alarm contacts support the listed external alarm connections.
• NEMA 1 identifies this unit for indoor or dry use.
• Forced-air cooling manages operating heat during charging.

Battery and Charging Compatibility

The La Marche MSM 24V/35A supports listed VRLA, AGM, and gel lead-acid batteries. Its single expandable output bank provides 24V DC charging for workboats, industrial marine systems, and emergency-power applications.

This 24 volt marine charger does not list lithium, NiCad, or flooded lead-acid compatibility. Configure absorption and float values only within battery manufacturer-approved limits.

Installation and System Considerations

The charger uses auto-sensing 102V to 264V AC input and provides one 24V DC expandable bank. NEMA 1 identifies it for indoor or dry use, while LCD status, alarm contacts, optional external temperature-probe support, forced-air cooling, AC and DC breakers, surge protection, and short-circuit protection are listed. The unit is non-ignition-protected, measures 12.2 in. by 8.7 in. by 5.5 in., and weighs 12 lbs. Installation should follow the charger manual and the electrical requirements applicable to the vessel.

Warranty and Support

Warranty information is not included in the listed product data. Review the manufacturer documentation for product details, setup, and warranty coverage.

Before Ordering the La Marche MSM 24V/35A Smart Charger

Before ordering, verify that your system uses one expandable 24V bank, accepts 102V to 264V AC input, and uses VRLA, AGM, or gel batteries. Review the NEMA 1 dry-use classification, non-ignition-protected status, display, alarm contacts, optional probe, and installation space. You should confirm compatibility with your battery manufacturer and vessel electrical system before purchase.
