Racor 1000VMA Fuel Filter

Description

Protecting a marine diesel fuel supply begins with a filter and water separator matched to the fuel-system flow and connection requirements. The Racor 1000VMA Fuel Filter is a single-assembly turbine fuel filter and water separator for marine diesel main engines, generator fuel feeds, and fuel polishing rigs.

This Racor single-turbine assembly has a maximum clean diesel-flow rating of 180 GPH (681 LPH/3.0 GPM) and a maximum internal operating pressure of 15.0 PSI (1.03 bar). It uses a 10-micron Aquabloc® corrugated Series 2020 cartridge and includes an impact-resistant clear collection bowl with a USCG metal protective heat shield.

Key Features of Racor 1000VMA

• Single-assembly turbine fuel filter and water separator provides diesel fuel filtration and water-separation service in one unit.
• 180 GPH (681 LPH/3.0 GPM) maximum clean diesel-flow rating identifies the listed flow capacity.
• 10-micron Aquabloc® corrugated element provides the listed filtration rating.
• Series 2020 cartridge designation identifies the specified filter element series.
• 15.0 PSI (1.03 bar) maximum internal operating pressure defines the listed system pressure limit.
• 7/8-inch-14 UNF SAE J1926 O-ring boss ports identify the listed connection thread and port style.
• Impact-resistant clear collection bowl allows visual inspection of the collection area.
• USCG metal protective heat shield is included with the clear-bowl configuration.
• Positive-seal self-venting manual water drain valve supports manual draining of collected water.
• Measures 22.0 x 6.0 x 7.0 inches (559 x 152 x 178 mm) and has a dry weight of 10.0 lb (4.5 kg).

Fitment and Maintenance Use

The Racor 1000VMA is specified for marine diesel main engines, generator fuel feeds, and fuel polishing rigs. It is intended to filter diesel fuel and separate collected water within the listed maximum clean flow rating of 180 GPH and maximum internal operating pressure of 15.0 PSI. The product data lists USCG approval and ABYC compliance for enclosed engine rooms. Confirm fitment using the engine model, serial number, and manufacturer service documentation before ordering.

Installation and Service Considerations

Verify that your fuel-system plumbing is compatible with the 7/8-inch-14 UNF SAE J1926 O-ring boss ports and that the planned location accommodates the 22.0 x 6.0 x 7.0 inch assembly. Do not exceed the listed 15.0 PSI maximum internal operating pressure. The clear bowl and positive-seal self-venting manual drain valve are supplied for collection-area inspection and manual water draining. Follow the engine manufacturer’s service manual and the product instructions for installation and service procedures. Verify the engine model and serial number before service.

Before Ordering the Racor 1000VMA

Confirm that Racor part number 1000VMA matches your marine diesel main engine, generator fuel feed, or fuel polishing rig. Verify the single-turbine fuel filter and water-separator design, 180 GPH (681 LPH/3.0 GPM) maximum clean flow rating, 10-micron Series 2020 Aquabloc® cartridge, 15.0 PSI (1.03 bar) maximum internal operating pressure, 7/8-inch-14 UNF SAE J1926 O-ring boss ports, clear bowl with metal heat shield, manual water drain valve, and 22.0 x 6.0 x 7.0 inch installation size. Confirm compatibility with your engine manufacturer’s documentation before purchase.
