Fischer Panda AGT-DC 4000 – 3.2kW 12V DC Supersilenced Generator
High-current 12V DC battery banks charge rapidly via the Fischer Panda AGT-DC 4000 marine genset, which pumps 240 Amps at 12V DC from a 290cc Farymann diesel, keeping sound at 52 dBA within a 90-kg capsule.
- 240-Amp direct current rapidly replenishes 12V banks
- 52 dBA soundproof capsule ensures quiet night anchoring
- 100-percent water-cooled housing requires zero ventilation louvers
- Automatic charging controller manages multi-stage battery cycles
- Weighs 90 kg easing small sailing vessel mounting
Products are almost sold out
available only:
3Description
The Fischer Panda AGT-DC 4000-12V PMS is a DC marine battery-charging generator for compatible 12V battery systems. It provides 3.2 kW continuous charging performance and up to 220A continuous charging current, with output current regulated according to battery voltage and charging demand. This is not a direct AC generator: it charges a DC battery bank, which can supply AC loads only through a separately selected compatible inverter.
The generator uses a Kubota EA300 single-cylinder diesel engine, permanent-magnet generator technology, and a water-cooled sound-insulation capsule. It is intended for permanently installed marine battery-charging applications and requires a compatible 12V battery bank, battery-management system where applicable, correctly sized DC cables, fuses, isolators, ventilation, fuel supply, raw-water cooling, exhaust, and qualified installation.
Key Specifications
- DC marine battery-charging generator, model AGT-DC 4000-12V PMS.
- Provides 3.2 kW continuous charging performance for a compatible 12V battery system.
- Supplies up to 220A continuous charging current, with current dependent on battery voltage and charging demand.
- Uses a Kubota EA300 single-cylinder diesel engine with 309 cc displacement.
- Uses a water-cooled marine generator design with a heat-exchanger cooling arrangement.
- Includes Fischer Panda automatic generator control for battery-charging operation.
- Uses a sound-insulation capsule and has a listed sound level of 54 dB(A) at 7 m.
- Listed dimensions are approximately 598 mm by 398 mm by 410 mm, excluding fittings, with a weight of approximately 90 kg.
Electrical Compatibility
This is a 12V DC charging generator, not a 120V or 230V AC source. Confirm battery-bank chemistry, battery-management-system requirements, permitted charge voltage and current, bank capacity, DC distribution, cable gauge, fuse ratings, disconnects, and charging profile before purchase. Lithium battery systems require confirmation with the battery and BMS manufacturer.
AC loads require a separate properly sized inverter connected to the battery bank. Assess inverter power, battery capacity, DC current, charging recovery time, and simultaneous loads before selecting a DC charging generator.
Installation Considerations
Mount the generator on a rigid vibration-isolated foundation with service access for oil, filters, cooling components, raw-water pump, exhaust, DC terminals, and capsule maintenance. Use correctly sized positive and negative conductors, battery fuses, isolators, and protected cable routing for high-current DC charging. Provide diesel fuel feed and return, seawater intake and strainer, exhaust, ventilation, start battery, and battery-bank integration. Installation and commissioning should be completed by a qualified marine generator technician.
Before Ordering
Confirm a compatible 12V battery bank, battery chemistry and BMS requirements, maximum permitted charging current up to 220A, battery-bank capacity, inverter and AC-load requirements, DC cable size, fuse and isolation design, available installation space, structural support for approximately 90 kg, diesel fuel layout, raw-water intake, exhaust route, ventilation, service access, and qualified DC marine-generator installation requirements before purchase.
Fischer Panda AGT-DC 4000 - 3.2kW 12V DC Supersilenced Generator
| Brand | Fischer Panda |
|---|---|
| Full Model SKU / Code | AGT-DC 4000 12V |
| Generator Type | Fixed Speed Direct Current (DC) Battery Charging Marine Generator |
| Continuous Power Output | 3.2 kW / 240 A |
| Voltage Output | 12 V DC |
| Frequency Output | N/A (Direct Current) |
| Engine Operating Speed | 3000 RPM |
| Engine Manufacturer & Model | Farymann 18W430 Single Cylinder Diesel Engine |
| Number of Cylinders | 1 Cylinder |
| Displacement | 290 cc |
| Cooling System Type | Dual-Circuit Freshwater/Seawater Heat Exchanger Cooling |
| Cooling Pump Type | 100% Water-Cooled Alternator & Engine Housing with Raw Water Impeller Pump |
| Fuel Type | Marine Diesel |
| Fuel Consumption (Average) | 0.7 - 1.1 L/h depending on load |
| Sound Insulation Enclosure | GFK 3D Sound Insulation Soundproof Capsule |
| Noise Level | 52 dB(A) @ 7m |
| Dimensions with Sound Shield (L x W x H) | 558 x 460 x 515 mm |
| Dry Weight | 90 kg |
| Control Panel | Automatic Battery Charging Controller Panel with Digital Status Display |
| Safety Protection Systems | Low Oil Pressure, High Engine/Alternator Temperature Cut-Off, Reverse Polarity Protection |
