Raymarine Yachtsense Link Marine Mobile Router

Description

Integrate cellular and Raymarine network connections with the Raymarine Yachtsense Link Marine Mobile Router. This marine mobile router is specified for full Raymarine network integration, with 4G LTE Cat 4, Wi-Fi, and RayNet compatibility plus dual Micro-SIM slots.

Raymarine part number E70640 operates on 12V or 24V DC with average power consumption of 10W. It provides four RayNet Ethernet ports, SeaTalkNG, digital I/O, and an integrated GPS/GLONASS antenna. The marine-grade polymer enclosure has an IPX6 rating listed as external-deck resistant, and a power/I/O cable with LTE antennas is included.

Key Features of Raymarine YachtSense Link

• Marine mobile router supports the listed full Raymarine network-integration application.
• 4G LTE Cat 4, Wi-Fi, and RayNet compatibility identifies the listed network connection types.
• Dual Micro-SIM slots provide the listed cellular-service interface count.
• 12V or 24V DC input supports the listed vessel-power options.
• Average 10W power consumption defines the listed electrical demand.
• Four RayNet Ethernet ports identify the listed Raymarine network connection count.
• SeaTalkNG interface provides the listed marine-network connection.
• Digital I/O is included as the listed equipment interface.
• Integrated GPS/GLONASS antenna identifies the listed positioning capability.
• IPX6 external-deck-resistant rating applies to the listed marine-grade polymer enclosure.

Network Compatibility and Use

The Raymarine YachtSense Link is specified for full Raymarine network integration using listed 4G LTE Cat 4, Wi-Fi, RayNet, SeaTalkNG, and digital-I/O connections. Its dual Micro-SIM slots, four RayNet Ethernet ports, SeaTalkNG interface, and included LTE antennas must match the vessel network and active cellular-service requirements. Actual cellular service, Wi-Fi access, and internet performance depend on carrier service, plan, coverage, signal conditions, network load, and configuration. Confirm compatibility with your router, modem, antenna system, vessel network, and manufacturer documentation before ordering.

Installation and Service Considerations

Verify a compatible 12V or 24V DC power source and account for the listed 10W average consumption. Confirm the required RayNet, SeaTalkNG, digital-I/O, SIM-card, and LTE antenna connections before installation. Select a location suited to the listed IPX6 external-deck-resistant enclosure and plan space for the 2.6 lb (1.2 kg) unit. A power/I/O cable and LTE antennas are included. the listed operating-temperature range is -13 degrees F to 131 degrees F (-25 degrees C to 55 degrees C). Follow the product instructions and your vessel electronics manufacturer’s documentation for mounting, cabling, power connections, sealing, and network setup.

Before Ordering the Raymarine YachtSense Link

Verify that Raymarine part number E70640 matches your Raymarine network-integration plan. Confirm the marine mobile router type, 4G LTE Cat 4, Wi-Fi, and RayNet compatibility, dual Micro-SIM slots, 12V or 24V DC input, 10W average power consumption, four RayNet Ethernet ports, SeaTalkNG, digital I/O, integrated GPS/GLONASS antenna, marine-grade polymer enclosure, IPX6 external-deck-resistant rating, -13 degrees F to 131 degrees F operating-temperature range, 2.6 lb dry weight, included power/I/O cable, included LTE antennas, and 2-year warranty with 3 years available through registration. Confirm compatibility with your router, modem, antenna system, vessel network, and manufacturer documentation before purchase.
