Furuno NavPilot 711C-S w/Octopus Pump 7ci to 12ci
Holding tight trolling tracks over structure, the Furuno NavPilot 711C-S heading computer couples an adjustable 1.2 L/min Octopus hydraulic pump with Fantum Feedback algorithms, steering 7-to-12-cubic-inch cylinders at 12V without mechanical rudder sensors.
- Octopus pump drives 7-to-12CI steering cylinders
- Fantum Feedback clears physical sensor clutter
- Adjustable flow rate optimizes cylinder speed
- IP56 display casing resists weather exposure
Products are almost sold out
available only:
6In Stock
Description
The Furuno NavPilot 711C-S combines an Octopus reversing pump with a controller and 4.1-inch display for hydraulic autopilot steering. The adjustable pump supports 7 to 12 cubic-inch cylinder volume, produces 1.0 to 1.2 liters per minute, and operates at a listed 50-bar pressure. The FAP-7002 processor manages the pump, while Fantum Feedback provides the listed steering-control function.
The package includes the Octopus pump, NavPilot 711C head, and processor. It operates from 12V DC, uses 1/4-inch NPT fittings, and supports vertical or horizontal pump mounting.
Key Specifications of the Furuno NavPilot 711C-S with Octopus Pump
- Adjustable reversing pump drives hydraulic steering.
- Cylinder compatibility ranges from 7 to 12 cubic inches.
- Flow rate ranges from 1.0 to 1.2 liters per minute.
- Maximum pressure is listed at 50 bar.
- 12V DC operation is specified.
- Peak current draw reaches 15 amps.
- Load-dependent draw ranges from 3 to 8 amps.
- Permanent magnet DC motor provides reversing operation.
- 1/4-inch NPT fittings provide hydraulic connections.
- Octopus pump, head, and processor are included.
Pump Function, Flow, and Controls
The included Octopus pump reverses hydraulic flow for the NavPilot 711C-S system and provides 1.0 to 1.2 liters per minute at the listed configuration. Fantum Feedback and dynamic software control manage the autopilot system, while the supplied data does not confirm self-priming, dry-run capability, or duty cycle.
Plumbing, Power, and Compatibility Considerations
Verify the 7 to 12 cubic-inch cylinder volume, 50-bar pressure rating, 1/4-inch NPT fittings, 12V supply, 15-amp peak draw, 3 to 8-amp load demand, FAP-7002 processor, and hydraulic hose kit before installation.
Mounting, Installation, and Environmental Conditions
Confirm the 115 by 115mm control-head dimensions, 185 by 95mm pump dimensions, vertical or horizontal pump mounting, hydraulic-line access, cable routing, operating temperature, and IP56 or IP55 ratings before installation.
Warranty and Support
Warranty coverage is not confirmed in the available product data. Buyers should verify current coverage, exclusions, and claim procedures with the seller or manufacturer before purchase. These terms reflect currently available manufacturer information, and buyers should verify active warranty policies directly with the seller or manufacturer before purchase.
Before Ordering the Furuno NavPilot 711C-S with Octopus Pump
Verify the 7 to 12 cubic-inch cylinder range, 1.0 to 1.2-liter flow, 50-bar pressure, 12V supply, current demand, NPT fittings, processor, pump mounting, and package contents before ordering.
