Garmin GHP SmartPump v2
Driving high-capacity steering cylinders without hydraulic cavitation, this Garmin SmartPump v2 hydraulic autopilot uses brushless motor engineering across 10V to 30V inputs, managing up to 24-cu-in rams via 9-axis AHRS leveling and Shadow Drive.
- Brushless motor enhances long-term mechanical reliability
- Universal pump fits 24-cu-in steering cylinders
- Shadow Drive allows instant manual override
- 9-axis AHRS eliminates compass calibration drift
Products are almost sold out
available only:
5In Stock
Description
Hydraulic steering control centers on the Garmin GHP SmartPump v2, which supports cylinders up to 24 cubic inches through a brushless pump and Reactor 40 nine-axis AHRS. Shadow Drive and SmartFlow technologies manage the steering system, while NMEA 2000 and ANT+ connectivity support the listed Garmin network functions. The pump accepts 10 to 30V DC input, draws less than 200mA at idle, and typically uses 1 to 2 amps.
The system includes the SmartPump v2, Reactor 40 CCU, ECU, Shadow Drive, and cables. The pump measures 7.8 by 7.5 by 9.6 inches, operates from minus 15 to 55 degrees Celsius, and carries an IPX7 rating.
Key Specifications of the Garmin GHP SmartPump v2 Hydraulic Autopilot System
- Brushless pump supports hydraulic steering applications.
- Cylinder compatibility extends up to 24 cubic inches.
- Reactor 40 CCU uses a nine-axis solid-state AHRS.
- Shadow Drive supports the listed steering function.
- SmartFlow manages hydraulic pump flow.
- NMEA 2000 provides certified network connectivity.
- ANT+ supports the listed Quatix connection.
- Input voltage ranges from 10 to 30V DC.
- Typical power consumption is 1 to 2 amps.
- SmartPump, CCU, ECU, Shadow Drive, and cables are included.
Pump Function, Flow, and Controls
The SmartPump v2 supplies hydraulic steering control for the Reactor 40 autopilot system. Its brushless motor, Shadow Drive, and SmartFlow technologies manage the listed steering operation, while the nine-axis AHRS provides heading reference through the CCU. The supplied data does not specify flow rate, shut-off pressure, self-priming height, dry-run operation, or continuous-duty rating.
Plumbing, Power, and Compatibility Considerations
Verify the hydraulic cylinder volume, steering-line arrangement, 10 to 30V DC supply, power wiring, grounding, NMEA 2000 connection, ANT+ equipment, and Shadow Drive installation before setup. Confirm that the selected hydraulic system remains within the stated 24 cubic inch cylinder limit.
Mounting, Installation, and Environmental Conditions
Confirm the 7.8 by 7.5 by 9.6 inch pump dimensions, hydraulic line access, CCU and ECU locations, cable routing, operating temperature, and IPX7 ratings before installation. Follow the supplied installation documentation for hydraulic connections and system commissioning.
Warranty and Support
The Garmin GHP SmartPump v2 Hydraulic Autopilot System includes a verified 2-Year Manufacturer Warranty. These terms reflect currently available manufacturer information, and buyers should verify active warranty policies directly with the seller or manufacturer before purchase.
Before Ordering the Garmin GHP SmartPump v2 Hydraulic Autopilot System
Verify the hydraulic cylinder volume, steering system, 10 to 30V DC supply, current draw, CCU and ECU locations, NMEA 2000 network, Shadow Drive, SmartFlow, included cables, and package contents before ordering.
Garmin GHP SmartPump v2
| Brand | Garmin |
|---|---|
| Model Name | GHP SmartPump v2 Autopilot System |
| Part Number/SKU | 010-00705-65 |
| Technology Category | Hydraulic Autopilot Steering System |
| Drive Unit Compatibility | Universal (Up to 24 cu in cylinders) |
| Heading Sensor | 9-axis Solid-state AHRS (Reactor 40 CCU) |
| Steering Technology | Shadow Drive™ & SmartFlow™ Technology |
| Motor Type | Brushless (Increased Reliability & Efficiency) |
| Voltage Input | 10V - 30V DC |
| Power Consumption | Idle: <200mA; Typical: 1A - 2A |
| Networking | NMEA 2000® Certified / ANT+ (Quatix Support) |
| Waterproofing | IPX7 (Pump, ECU, and CCU) |
| Dimensions (Pump) | 7.8" x 7.5" x 9.6" (197 x 190 x 244 mm) |
| Operating Temp | -15°C to 55°C (5°F to 131°F) |
| In-Box Contents | SmartPump v2, Reactor 40 CCU, ECU, Shadow Drive, Cables |
| Standard Warranty | 2-Year Manufacturer Warranty |
