Anchor Winch Captain EZ-2 134-0128 – Stainless Steel Direct Drive Drum Anchor Winch For Boats To 27

Description

TheCaptain EZ-2is a horizontal direct-drive captive drum winch with a 700W 12V DC motor. The winch has a stated maximum pull of 882 lbs and a 220 lbs continuous working-load rating. Its marine-grade 316 stainless steel casing and drive shaft form the listed drum and drive assembly.

The captive drum holds up to 60 m of 8 mm rope or 45 m of 10 mm rope with a chain leader. A mechanical manual free-spool release provides the listed release function. The provided product data does not confirm an anchor, rope, chain leader, controls, contactor, or circuit breaker as included.

Key Features of the EZ-2 Drum Anchor Winch

• The 700W 12V DC motor powers horizontal direct-drive drum retrieval.
• The captive drum holds up to 60 m of 8 mm rope.
• The drum holds up to 45 m of 10 mm rope plus chain leader.
• The mechanical manual system provides the listed free-spool release function.
• The 220 lbs working-load rating identifies the continuous hauling load.
• The 882 lbs maximum pull figure states the product’s peak pull rating.
• the listed no-load speed reaches 98 ft/min without a working load.
• The 316 stainless steel casing forms the listed drum housing.
• The watertight enclosure carries the listed IP66 protection rating.
• An 80A circuit breaker is required for electrical protection.

Which Boats This Drum Winch Fits

The EZ-2 drum anchor winch is recommended for powerboats and runabouts up to 27 ft. Its captive drum holds either 60 m of 8 mm rope or 45 m of 10 mm rope with a chain leader. Buyers should verify rope diameter, rope length, chain-leader arrangement, and available drum capacity before ordering.

the listed maximum pull is 882 lbs. The 220 lbs working-load rating provides the separate continuous hauling value. Buyers should use the continuous rating when considering regular retrieval requirements.

Materials, Technology and Use

The marine-grade 316 stainless steel casing and drive shaft form the listed drum-winching assembly. The IP66 rating applies to the watertight enclosure. The direct-drive layout includes a mechanical manual free-spool release for the listed release function.

Salt residue, sand, and debris can still accumulate around the stainless steel casing, drum, rope, chain leader, and deck hardware. Regular cleaning and inspection remain necessary. The captive drum stores the listed rode capacity without a rope-to-chain gypsy.

Compatibility and Installation

The Captain drum winch measures 255 mm high by 310 mm wide and weighs 33 lbs. Installers should verify deck structure, mounting space, cable routing, drum clearance, and access to the free-spool release before installation. The available product details do not list a deck-thickness range.

The 12V DC system requires an 80A circuit breaker. Electrical planning can include battery charging direction around the listed circuit-protection requirement. The provided product data does not state average current draw or confirm controls, contactor, or circuit breaker as included.

Care and Operating Notes

Rinse the casing, drum, rope, chain leader, and exposed hardware with fresh water after saltwater exposure. Remove salt, sand, mud, and debris from the drum and manual release mechanism before operation. Inspect rope condition, chain leader, release movement, visible fasteners, and electrical connections before departure. Follow the manufacturer manual for service procedures, lubricant selection, disassembly, and approved replacement parts.

Warranty and Support

The EZ-2 carries a 3-year limited warranty on the motor and gearbox. The provided warranty term does not define coverage for labor, corrosion, drum, rope, chain leader, shipping, or installation components. These terms reflect manufacturer-stated coverage, and buyers should verify active warranty policies directly with the seller or manufacturer prior to purchase.

Before Ordering

Confirm whether your anchor rode uses up to 60 m of 8 mm rope or up to 45 m of 10 mm rope with a chain leader. You should compare your boat with the up-to-27-ft application guide, reserve space for the 255 mm by 310 mm housing, and account for the 33 lbs dry weight. Verify that your 12V system can use the required 80A circuit breaker. Confirm controls, contactor, circuit protection, anchor, rope, chain leader, and mounting hardware with the seller because the provided product data does not confirm them as included.
