Garmin Class B Compact v2 Drive Unit
Confined steering flats on sailboats up to 28,500 lbs accommodate this Garmin Class B Compact linear drive, which delivers 1,100 lbs of hydraulic thrust across a 250mm stroke within an integrated hose-free chassis at 16.5 lbs.
- 1100-lb peak thrust moves rudder quadrants
- Space-saving 120mm profile fits tight flats
- Zero external hoses prevent hydraulic leaks
- Draws 2A to 4A sailing cruising
- IPX6-rated housing withstands harsh bilge conditions
Products are almost sold out
available only:
4In Stock
Description
The Garmin Class B Compact v2 Drive Unit is a self-contained hydraulic linear actuator for compatible mechanically steered sailboats and displacement vessels. It connects to an independent tiller arm or steering quadrant through a pivot and clevis linkage, combining the hydraulic pump and ram in one compact assembly. This is a drive-only component and requires a compatible Garmin Reactor 40 Mechanical autopilot system, high-current ECU, control display or chartplotter, heading sensor, power circuit, and correctly engineered steering linkage.
The 12V drive provides a 250 mm linear stroke and up to 500 kg, or 1,100 lb, peak thrust. It can draw up to 15A under maximum load and is intended for vessels up to 13,000 kg, or 28,500 lb, displacement. The compact integrated design eliminates external hydraulic hoses between the pump and ram, but it still requires a rigid mounting foundation, correct steering geometry, and full manual-rudder travel.
Key Specifications
- Self-contained 12V hydraulic linear autopilot drive for compatible mechanically steered vessels.
- Designed for compatible sailboats and displacement vessels up to 13,000 kg, or 28,500 lb.
- Provides a 250 mm linear push-pull stroke.
- Delivers up to 500 kg, or 1,100 lb, peak thrust.
- Uses an integrated reversing DC hydraulic pump with no external pump-to-ram hose requirement.
- Draws up to 15A under maximum steering load.
- Connects to a compatible steering quadrant or independent tiller arm through a pivot-foot and clevis linkage.
- Weighs approximately 7.5 kg and uses anodized aluminum and stainless-steel construction for protected marine installation.
System Integration
This is not a complete autopilot system. It requires a Garmin Reactor 40 Mechanical corepack or other Garmin-approved high-current system configured for the correct drive class, plus a compatible control display or chartplotter, heading sensor, power circuit, and feedback arrangement where required. Do not connect it to a low-current autopilot computer or wheel-drive controller.
Match the drive to actual vessel displacement, rudder torque, steering-arm radius, stroke requirement, maximum drive current, and manual-steering arrangement. A physical rudder-feedback sensor may be required depending on the selected Reactor 40 configuration and vessel steering system.
Installation Considerations
Install the actuator under deck on a rigid foundation with pivot points aligned to prevent binding, side loading, over-travel, or restricted manual steering. Confirm that the entire 250 mm stroke is available before installation. Use correctly sized marine-grade wiring, suitable 15A circuit protection, secure terminals, and protected cable routing. Follow Garmin dockside configuration and sea-trial procedures after installation.
Before Ordering
Confirm vessel displacement up to 28,500 lb, compatible mechanical steering, an independent tiller arm or steering quadrant, sufficient 250 mm stroke clearance, structural mounting strength, Garmin Reactor 40 Mechanical compatibility, approved drive-class configuration, 12V supply, 15A circuit capacity, feedback requirement, manual-steering access, and complete autopilot-system components before purchase.
Garmin Class B Compact v2 Drive Unit
| Drive Type | Compact Hydraulic Linear Drive |
|---|---|
| Pump/Ram Capacity | Integrated Precision Hydraulic System |
| Flow Rate / Speed | Hard-over to Hard-over: 13 Seconds |
| Max Pressure | 1,100 lbs (500 kg) Peak Thrust |
| Cylinder Compatibility | Sailboats up to 28,500 lbs (13,000 kg) |
| Operating Voltage | 12V DC System |
| Peak Current Draw | 15 Amps Maximum |
| Average Power Draw | 2A - 4A Typical Sailing Conditions |
| Motor Type | Integrated Reversing DC Pump |
| Computer Compatibility | Reactor 40 Mechanical Corepack |
| Port Size / Thread | Self-Contained (Zero External Hoses) |
| Drive Connection | Tiller Arm / Quadrant Pin |
| Rotation/Stroke Direction | Linear Push-Pull (250mm Stroke) |
| Mounting Type | Fixed Pivot Foot Bracket |
| Housing Material | Anodized Aluminum & Stainless Steel |
| Waterproof Rating | IPX6 Marine Protected |
| Operating Temperature | -15°C to +60°C Extreme Performance |
| Length (Overall) | 710 mm Fully Extended |
| Width/Diameter | 120 mm Slim Profile Chassis |
| Weight | 7.5 kg (16.5 lbs) |
| Included Accessories | Mounting Pin, Clevis, Hardware |
| Key Mechanical Feature | Space-saving design for confined steering flats |
