Garmin Compact Reactor 40 Hydraulic Autopilot w/GHC 50 Instrument Pack w/GHC 50
Single-engine coastal center consoles gain automated waypoint tracking from this Garmin Compact Reactor 40 marine autopilot, utilizing self-learning algorithms, an included 1.0L hydraulic pump, and a 5-inch GHC 50 touchscreen instrument pack.
- 9-axis AHRS maintains 2-degree heading accuracy
- GHC 50 color touchscreen displays real-time telemetry
- Included 1.0L pump moves hydraulic lines
- Shadow Drive sensor enables manual avoidance turns
- Dockside wizard accelerates initial autopilot calibration
Products are almost sold out
available only:
7In Stock
Description
Hydraulic steering control for smaller vessels is provided by the Garmin Compact Reactor 40 Hydraulic Autopilot with GHC 50. The system combines a 1.0-liter pump, Reactor 40 ECU and CCU, GHC 50 touchscreen, nine-axis solid-state AHRS, and Shadow Drive. It supports hydraulic cylinders up to 6.1 cubic inches and operates from 10 to 20V DC.
NMEA 2000, ANT+, Wi-Fi, dockside setup, and self-learning functions are listed for the system. Verify the cylinder volume, hydraulic steering arrangement, power supply, control-unit location, and included components before installation.
Key Specifications of the Garmin Compact Reactor 40 Hydraulic Autopilot with GHC 50
- 1.0-liter pump supports the included hydraulic system.
- Cylinder compatibility extends up to 6.1 cubic inches.
- GHC 50 provides a 5-inch touchscreen control.
- Reactor 40 ECU controls the autopilot system.
- Nine-axis AHRS provides heading reference.
- Shadow Drive provides the listed steering override.
- NMEA 2000 provides certified system networking.
- ANT+ and Wi-Fi functions are listed.
- 10 to 20V DC defines the input range.
- GHC 50, CCU, ECU, pump, and Shadow Drive are included.
Pump Function, Flow, and Controls
The included 1.0-liter pump supplies hydraulic steering drive for the Compact Reactor 40 system. The GHC 50, ECU, CCU, AHRS, Shadow Drive, and self-learning algorithms provide the listed control functions. Pump flow rate, pressure, self-priming height, dry-run operation, and duty cycle are not specified.
Plumbing, Power, and Compatibility Considerations
Verify the hydraulic cylinder volume, 10 to 20V DC supply, pump arrangement, NMEA 2000 network, GHC 50 control, ECU connections, Shadow Drive, and optional rudder-reference requirements before installation. Confirm that the steering system matches the stated cylinder limit.
Mounting, Installation, and Environmental Conditions
Confirm the 5.5 by 4.1 by 2.0 inch control-head dimensions, bulkhead or flush mounting, hydraulic line access, cable routing, operating temperature, and IPX7 rating before installation. Use the Garmin dockside wizard and supplied installation documentation during commissioning.
Warranty and Support
Warranty coverage is not confirmed in the available product data. Buyers should verify current coverage, exclusions, and claim procedures with the seller or manufacturer before purchase. These terms reflect currently available manufacturer information, and buyers should verify active warranty policies directly with the seller or manufacturer before purchase.
Before Ordering the Garmin Compact Reactor 40 Hydraulic Autopilot with GHC 50
Verify the 6.1 cubic-inch cylinder limit, 1.0-liter pump, 10 to 20V DC supply, GHC 50 control, NMEA 2000 network, Shadow Drive, rudder reference, mounting location, and package contents before ordering.
Garmin Compact Reactor 40 Hydraulic Autopilot w/GHC 50 Instrument Pack w/GHC 50
| Display Type | GHC 50 (5-inch Touchscreen) |
|---|---|
| Control Unit | Reactor 40 ECU |
| Drive Unit Compatibility | 1.0L Pump (Included) |
| Max Boat Displacement | Vessels under 30ft |
| Steering Type | Hydraulic |
| Heading Sensor | 9-axis Solid-state AHRS |
| Operating Voltage | 10V to 20V DC |
| Power Consumption (Idle) | Less than 200 mA |
| Power Consumption (Typical) | 1A to 2A |
| Networking (NMEA 2000/0183) | NMEA 2000 Certified |
| Wireless Capabilities | ANT+ / Wi-Fi |
| Integration (MFD Support) | Full Garmin Marine Network |
| Sea State Optimization | Self-learning Algorithms |
| Course Accuracy | +/- 2 degrees |
| Rudder Reference Support | Shadow Drive™ Technology Included |
| Commissioning Method | On-deck Wizard |
| Waterproof Rating | IPX7 |
| Operating Temperature | -15°C to 55°C |
| Mounting Options | Bulkhead / Flush Mount |
| Dimensions (Control Head) | 5.5" x 4.1" x 2.0" |
| In-box Contents | GHC 50, Reactor 40 CCU/ECU, 1.0L Pump, Shadow Drive |
| Key Features | All-in-one pack for smaller hydraulic boats |
