OBERDORFER 600-F13 Centrifugal Pump

Description

Move high volumes of water for ballast transfer, emergency bilge pumping, or deck-washdown systems with the Oberdorfer 600-F13 High-Capacity Marine Centrifugal Pump. This flooded-suction, non-self-priming centrifugal pump provides a maximum rated flow of 4,080 GPH (68 GPM / 15.4 m³/h), maximum head of 46 ft (14.0 m), and maximum pressure of 20.0 PSI.

Oberdorfer model 600-F13 combines a 1/2 HP (0.37 kW) TEFC motor with a heavy cast marine-bronze casing, open bronze impeller rated to tolerate solids up to 3 mm, stainless-steel drive shaft, and heavy-duty lip seal. It operates on 115V or 230V AC, single-phase, 60 Hz power and has 1-inch NPT female inlet and outlet ports. The pump supports continuous liquid temperatures up to 200 degrees F (93 degrees C).

Key Features

• High-capacity marine centrifugal pump for ballast transfer, emergency bilge pumping, and deck washdown.
• Flooded-suction non-self-priming design.
• Maximum rated flow of 4,080 GPH, 68 GPM, or 15.4 m³/h.
• Maximum rated head of 46 ft (14.0 m) and maximum pressure of 20.0 PSI.
• 1/2 HP (0.37 kW) TEFC motor.
• 115V or 230V AC, single-phase, 60 Hz dual-voltage power.
• Heavy cast marine-bronze casing.
• Open bronze impeller rated to tolerate solids up to 3 mm.
• Stainless-steel drive shaft and heavy-duty lip seal.
• 1-inch NPT female inlet and outlet ports.

Compatibility and Installation

The Oberdorfer 600-F13 is specified for compatible ballast, bilge, and deck-washdown systems. Confirm the selected 115V or 230V wiring configuration, 60 Hz power supply, circuit protection, 1-inch NPT plumbing, required operating flow, system head, liquid compatibility, and dry mounting location before ordering. This unit is non-self-priming and requires flooded suction or another manufacturer-approved installation arrangement.

Actual flow varies with total dynamic head, plumbing diameter and length, fittings, intake and discharge restrictions, strainer condition, fluid conditions, and supply voltage. The open impeller’s stated 3 mm solids tolerance does not eliminate the need for appropriate intake screening or strainers. Do not exceed the 200 degrees F continuous-duty liquid-temperature rating. This pump does not independently fulfill vessel emergency-dewatering requirements; confirm the complete installation against vessel and regulatory requirements.

Before Ordering

Verify Oberdorfer model 600-F13, high-capacity non-self-priming centrifugal configuration, 1/2 HP TEFC motor, 115V or 230V AC single-phase 60 Hz power, 4,080 GPH maximum flow, 46 ft maximum head, 20.0 PSI maximum pressure, cast-bronze casing, open bronze impeller with stated 3 mm solids tolerance, stainless-steel shaft, heavy-duty lip seal, 1-inch NPT female ports, 200 degrees F maximum liquid temperature, 305 x 152 x 178 mm dimensions, 25 lb dry weight, and 1-year limited manufacturer warranty before purchase.
