Quick RRC R902 Radio Remote Control Receiver – 2 Relays

Description

TheQuick RRC R902is a two-relay digital radio receiver for 12V and 24V DC marine control systems. It operates across a 10.5V to 31V DC supply range and uses two microprocessor-controlled relays for up-and-down operation. Each relay has a stated maximum contact current of 5A.

The receiver uses a 434.420 MHz carrier frequency with an internal antenna and pairs with Quick RRC P902 and H902 handheld transmitters. Its IP66 splashproof enclosure measures 116 mm high by 80 mm wide. The provided product data does not confirm a transmitter, wiring, fuses, circuit breakers, mounting hardware, or controlled equipment as included.

Key Features of the RRC R902 Radio Receiver

• The receiver operates from 10.5V to 31V DC power supplies.
• The unit supports 12V and 24V DC marine electrical systems.
• Two microprocessor-controlled relays provide the listed up-and-down operation.
• Each relay has a stated maximum contact current of 5A.
• The receiver uses a 434.420 MHz radio carrier frequency.
• An internal antenna forms part of the listed receiver configuration.
• The receiver pairs with Quick RRC P902 handheld transmitters.
• The receiver also pairs with Quick RRC H902 handheld transmitters.
• The IP66 splashproof enclosure measures 116 mm by 80 mm.
• the listed operating temperature range spans 5°F to 158°F.

Equipment Compatibility

The RRC R902 receiver pairs with Quick RRC P902 and H902 handheld transmitters. Its two-relay arrangement provides the listed up-and-down control function. Installers should verify that the connected windlass, winch, or other equipment uses a control interface compatible with two 5A relay contacts before adding the receiver.

The receiver accepts 10.5V to 31V DC, covering the listed 12V and 24V compatibility range. The available product details do not list compatibility with other transmitters, control modules, contactors, or specific windlass models.

Materials, Protection and Use

The IP66 rating applies to the splashproof marine enclosure. The internal antenna receives the listed 434.420 MHz carrier signal from compatible handheld transmitters. Salt, moisture, and debris can still collect around the enclosure, cable entries, and connected terminals, so installers should inspect and clean those areas regularly.

The receiver operates within a stated temperature range from 5°F to 158°F. Follow manufacturer documentation for transmitter pairing, wiring, relay connections, mounting, and approved replacement components.

Compatibility and Installation

The Quick radio receiver operates on 10.5V to 31V DC and uses two relay outputs with a stated 5A maximum contact current. Installers should verify the controlled equipment’s switching requirements, relay-contact limits, wiring layout, circuit protection, and mounting location before connection.

For installations supplied from an onboard DC system, electrical planning can include marine charging coordination within the wider control layout. The provided product data does not confirm transmitters, cables, fuses, breakers, contactors, or mounting hardware as included.

Care and Operating Notes

Inspect the enclosure, cable entries, terminals, and connected wiring for salt residue, moisture, heat damage, or loose connections before operating controlled equipment. Keep the receiver enclosure and terminal areas clear of sand and debris. Follow the manufacturer manual for pairing, wiring, service procedures, and approved replacement parts.

Warranty and Support

The RRC R902 carries a 2-year limited manufacturer warranty. The provided warranty term does not define coverage for labor, corrosion, connected equipment, shipping, wiring, or installation components. These terms reflect manufacturer-stated coverage, and buyers should verify active warranty policies directly with the seller or manufacturer prior to purchase.

Before Ordering

Confirm that your onboard system operates within the 10.5V to 31V DC range and that the controlled equipment accepts two relay outputs with a 5A maximum contact-current rating. You should verify compatibility with Quick RRC P902 or H902 transmitters, the 434.420 MHz receiver arrangement, wiring requirements, circuit protection, and mounting space before ordering. The provided product data does not confirm a transmitter, cable, fuse, breaker, contactor, or mounting hardware as included.
