AB Navigo 10 VS 10’6″ Fiberglass Open RIB Yacht Tender

Description

Using a hand-laid fiberglass deep-V hull and double molded deck system, the AB Inflatables Navigo 10 VS is a 3.20 m, or 10 ft 6 in, open fiberglass rigid inflatable boat and yacht tender. The flat fiberglass deck uses a non-skid surface, while three buoyancy tubes use ORCA CSM 1100 dtex fabric with cold-cured hand-laminated seams. Plan lifting, storage, trailer, and dock arrangements around the 115 kg, or 253 lb, net weight.

ISO capacity is four persons, and the 450 kg, or 992 lb, maximum payload sets the stated passenger and cargo limit. A 15-inch short-shaft outboard matches the specified transom configuration, with 10 HP recommended, 15 HP maximum, and a 55 kg, or 121 lb, engine-weight limit. Leafield C7 Push-Push valves serve the three buoyancy chambers, while CE Category C applies to the stated inshore and coastal classification.

Key Specifications of the AB Inflatables Navigo 10 VS Rigid Inflatable Boat

• The open fiberglass yacht tender measures 3.20 m, or 10 ft 6 in, overall and has a 115 kg net weight.
• A hand-laid fiberglass deep-V hull with double molded deck construction defines the documented rigid-hull configuration for this open RIB.
• The hand-laid fiberglass flat deck uses a non-skid surface, establishing the stated deck arrangement for the open boat layout.
• Three buoyancy tubes use ORCA CSM 1100 dtex fabric with cold-cured hand-laminated seams for the documented tube construction.
• ISO capacity is four persons, and the 450 kg maximum payload sets the stated passenger and cargo limit.
• A 15-inch short-shaft outboard is required, with 10 HP recommended and 15 HP maximum for propulsion selection.
• Outboard weight must not exceed 55 kg, requiring engine selection within the stated transom-loading limit before rigging.

Hull, Deck, and Capacity

An internal length of 2.40 m, or 7 ft 10 in, and an internal width of 0.79 m, or 2 ft 7 in, define the stated usable hull space. A 0.41 m, or 16 in, tube diameter accompanies the fiberglass deep-V hull, flat deck, double molded deck system, and three buoyancy chambers.

Included equipment consists of a bow locker with integrated seat and cushion, fiberglass molded seat, non-skid deck, heavy-duty rub rail, stainless steel bow and stern lifting rings, and self-bailing valve. Use the Leafield C7 Push-Push valves for the tube system, then keep passenger loading, payload, outboard-power, and engine-weight figures within the stated limits.

Why Choose the AB Inflatables Navigo 10 VS Rigid Inflatable Boat

The Navigo 10 VS rigid inflatable boat combines a 3.20 m fiberglass deep-V hull with an open deck, molded seating, bow locker, stainless lifting rings, and three ORCA CSM buoyancy chambers. Its 115 kg net weight, four-person ISO capacity, 450 kg payload rating, short-shaft outboard requirement, 10 HP recommended power, 15 HP maximum power, and 55 kg engine limit provide useful comparison details for an open fiberglass yacht tender.

Setup and Outboard Considerations

Included components cover a bow locker with integrated seat and cushion, fiberglass molded seat, non-skid deck, heavy-duty rub rail, stainless steel bow and stern lifting rings, and self-bailing valve. Match the transom with a 15-inch short-shaft outboard, then keep engine output at or below 15 HP and engine weight at or below 55 kg. Inflate all three buoyancy chambers through the Leafield C7 Push-Push valves.

Warranty and Support

AB Inflatables provides a 10-Year Limited Warranty covering ORCA CSM fabric and fiberglass hull structure. Before checkout, Mulmarine.com can help you review the 3.20 m hull dimensions, 115 kg net weight, 450 kg payload limit, short-shaft outboard requirement, and 55 kg engine-weight limit against your lifting, trailer, storage, and propulsion plan. Review the stated warranty coverage and documented included components before ordering.

Before Ordering the AB Inflatables Navigo 10 VS Rigid Inflatable Boat

Confirm that your lifting, trailer, dock, and storage plan supports the 3.20 m overall length and 115 kg net weight. You should use a 15-inch short-shaft outboard, select 10 HP as the recommended power level, avoid exceeding 15 HP or 55 kg engine weight, and remain within the four-person and 450 kg maximum capacity limits.
