AB Rider 10’6″ GRP Jockey Console Yacht Tender

Description

Using a jockey-console layout, the AB Inflatables AB Rider combines a 3.20 m, or 10 ft 6 in, deep-V fiberglass hull with a double molded deck system. The hand-laid deck has an integrated molded non-skid surface, while three buoyancy tubes use ORCA CSM 1100 dtex fabric with cold-cured hand-laminated seams. At 165 kg, or 363 lb, the boat should be assessed against the planned lifting, storage, trailer, and dock arrangement.

ISO capacity is four persons, and the 450 kg, or 992 lb, maximum payload applies to combined passenger and cargo loading. A 22 L, or 5.8 gal, fuel tank is integrated into the specified configuration. The transom requires a 15-inch short-shaft outboard, with 15 HP recommended, 25 HP maximum, and a 70 kg, or 154 lb, engine-weight limit.

Key Specifications of the AB Inflatables AB Rider Rigid Inflatable Boat

• The sport jockey-console RIB measures 3.20 m, or 10 ft 6 in, overall and has a 165 kg net weight.
• A hand-laid fiberglass deep-V hull uses a double molded deck system, defining the stated rigid-hull configuration for this tender.
• The fiberglass deck includes an integrated molded non-skid surface, establishing the specified deck arrangement beneath the jockey-console layout.
• Three buoyancy tubes use ORCA CSM 1100 dtex fabric with cold-cured hand-laminated seams for the documented tube construction.
• ISO capacity is four persons, and the 450 kg maximum payload sets the stated passenger and cargo limit.
• An integrated 22 L, or 5.8 gal, fuel tank forms the specified onboard fuel-storage arrangement for this compact RIB.
• A 15-inch short-shaft outboard is required, with 15 HP recommended and 25 HP maximum for propulsion selection.

Hull, Deck, and Capacity

An internal length of 2.40 m, or 7 ft 10 in, and an internal width of 0.79 m, or 2 ft 7 in, define the stated usable hull space. A 0.41 m, or 16 in, tube diameter accompanies the deep-V fiberglass hull, double molded deck, and three-chamber tube configuration.

Included equipment consists of a jockey console with steering cable and wheel, padded jockey seat with storage, integrated fuel tank, bow storage locker, automatic bilge pump, and stainless steel lifting eyes. Leafield C7 Push-Push valves serve the buoyancy tubes, while CE Category C applies to the stated inshore and coastal classification.

Why Choose the AB Inflatables AB Rider Rigid Inflatable Boat

The AB Rider rigid inflatable boat combines a 3.20 m deep-V fiberglass hull with a jockey console, padded storage seat, 22 L fuel tank, bow storage locker, and three ORCA CSM buoyancy chambers. Its 165 kg net weight, four-person ISO capacity, 450 kg payload rating, 15-inch short-shaft requirement, 15 HP recommended power, 25 HP maximum power, and 70 kg engine limit give buyers defined comparison points for a compact console tender.

Setup and Outboard Considerations

Included components cover the jockey console with steering cable and wheel, padded seat with storage, fuel tank, bow locker, bilge pump, and stainless steel lifting eyes. Match the transom with a 15-inch short-shaft outboard, then keep engine output at or below 25 HP and engine weight at or below 70 kg. Inflate all three buoyancy chambers through the Leafield C7 Push-Push valves.

Warranty and Support

AB Inflatables provides a 10-Year Limited Warranty covering ORCA CSM fabric and fiberglass hull structure. Mulmarine.com can help you review the 3.20 m hull dimensions, 165 kg net weight, jockey-console layout, 22 L fuel-tank specification, short-shaft outboard requirement, and stated capacity and engine limits against your tender, lift, trailer, dock, and propulsion plan before purchase. Review the stated warranty coverage and documented included components before ordering.

Before Ordering the AB Inflatables AB Rider Rigid Inflatable Boat

Confirm that your lifting, trailer, dock, and storage plan supports the 3.20 m overall length and 165 kg net weight. You should use a 15-inch short-shaft outboard, select 15 HP as the recommended power level, avoid exceeding 25 HP or 70 kg engine weight, confirm the 22 L fuel-tank configuration, and remain within the four-person and 450 kg maximum capacity limits.
