SCOT PUMP Vented Loop 7/8″ 316 Stainless Steel
Safeguarding small marine engine exhaust lines, the SCOT PUMP Vented Loop 7/8″ stops siphon action across 7/8-inch hoses using an internal duckbill valve inside electropolished 316 stainless steel.
- 7/8″ tube fits small bilge lines.
- Internal duckbill valve vents vacuum pressure.
- 316 stainless body withstands engine heat.
- Pre-welded bracket secures engine room bulkheads.
- Above-waterline placement prevents hull flooding risks.
Products are almost sold out
available only:
13In Stock
Description
Help prevent siphoning in small bilge-pump discharge lines and engine raw-water exhaust-injection systems with the SCOT Pump VL-0875-SS316 7/8-Inch Vented Loop. This compact anti-siphon siphon-break loop is specified for 7/8-inch (22 mm) marine hose.
The VL-0875-SS316 uses electropolished marine-grade 316 stainless steel and an integrated one-way atmospheric air vent with an internal duckbill valve. A pre-welded heavy-duty 316 stainless-steel mounting bracket is included for vertical above-waterline bulkhead mounting. The unit has a listed dry weight of 2.5 lb (1.1 kg).
Key Features
- Compact marine anti-siphon siphon-break loop for compatible 7/8-inch hose systems.
- Specified for small bilge-pump discharge and engine raw-water exhaust-injection applications.
- 7/8-inch (22 mm) marine-hose compatibility.
- Electropolished marine-grade 316 stainless-steel construction.
- Integrated one-way atmospheric air vent.
- Internal duckbill valve.
- Pre-welded heavy-duty 316 stainless-steel mounting bracket included.
- Vertical above-waterline bulkhead-mounting configuration.
- Dry weight of 2.5 lb (1.1 kg).
- Made in the USA.
Compatibility and Installation
The SCOT Pump VL-0875-SS316 is intended for compatible 7/8-inch bilge-discharge or raw-water exhaust-injection hose. Confirm the actual hose inside diameter, connected system requirements, waterline relationship, installation location, and vertical clearance before purchase. This siphon-break loop does not replace correctly selected seacocks, through-hull fittings, shutoff valves, hose clamps, exhaust components, or other required vessel-system hardware.
Install vertically on a suitable bulkhead above the waterline and maintain access to the vent valve for inspection and service. Follow SCOT Pump instructions and applicable requirements for the connected bilge-discharge or engine raw-water exhaust-injection system. Have marine plumbing and engine-system work performed by qualified personnel when required.
Before Ordering
Verify SCOT Pump model VL-0875-SS316, 7/8-inch hose ID compatibility, electropolished 316 stainless-steel construction, integrated atmospheric vent with internal duckbill valve, included welded mounting bracket, vertical above-waterline installation requirement, intended bilge or exhaust-injection application, 2.5 lb dry weight, and 1-year limited manufacturer warranty before purchase.
SCOT PUMP Vented Loop 7/8" 316 Stainless Steel
| Brand | SCOT Pump |
|---|---|
| Model / SKU | VL-0875-SS316 |
| Country of Origin | USA |
| Product Classification | Compact Anti-Siphon Siphon Break Loop |
| Body Material | Electropolished Marine-Grade 316 Stainless Steel |
| Hose Inside Diameter (ID) | 7/8" (22 mm) Marine Hose |
| Valve Technology | Integrated One-Way Atmospheric Air Vent with Internal Duckbill Valve |
| Installation Placement | Above-Waterline Vertical Bulkhead Mounting |
| Mounting Hardware | Pre-Welded Heavy-Duty 316 Stainless Steel Mounting Bracket |
| Product Dry Weight | 1.1 kg (2.5 lbs) |
| Primary Application | Small Bilge Pump Discharge Lines & Engine Raw Water Exhaust Injection |
| Standard Warranty | 1 Year Limited Manufacturer Warranty |
