CTM PCX1500 – 1500 GPH – 115/230V – 50/60HZ – 3.00″ Impeller – Marine Centrifugal Pump
- Volumetric Flow Rate: Absolute 5.6 m³/h (1500 GPH) Capacity.
- Pump Technology: Magnetic Drive Centrifugal (Seal-less).
- Electrical Compatibility: Dual-voltage 115/230V (50/60Hz).
- Material Construction: Glass-filled Polypropylene with Ceramic Shaft.
- Inlet/Outlet Interface: 1″ FPT Inlet / 3/4″ MPT Outlet.
Products are almost sold out
available only:
7In Stock
Description
CTM PCX1500 Centrifugal Pump
Engineered for high-volume liquid transfer, the CTM PCX1500 stands as the definitive fluid solution for a precision physical bridge to vessel safety. As a premier CTM marine pump, this unit utilizes a 3.00″ impeller to deliver superior hydrodynamic energy recovery through a massive 1500 GPH output. The hardware architecture focuses on technical precision, ensuring this CTM power system maintains optimal head pressure during continuous full-load operations in commercial and luxury maritime environments.
Technology-driven mechanical performance provides total protection through a dual-frequency 50/60HZ motor interface that facilitates global maritime operation. This CTM marine pump features a ruggedized frame to facilitate operation in the most punishing engine room conditions. Reliability is reinforced by the precision-ground gears and premium mechanical seals designed for professional maritime service. This unit is the premier choice for mariners prioritizing professional maritime power and 1500 GPH centrifugal pump integrity.
Key Technical Specifications
- 1500 GPH maximum flow rate.
- 3.00 inch precision machined impeller.
- 115/230V universal voltage system.
- 50/60HZ dual frequency compatibility rating.
- Rugged corrosion resistant hardware finish.
- High volume fluid transfer efficiency.
- Designed for marine engine cooling.
CTM PCX1500 Technical Specs
| Brand | CTM Marine |
| Full Model Code | PCX1500 |
| Pump Type | Magnetic Drive Centrifugal |
| Primary Application | Marine A/C Circulation |
| Body/Casing Material | Glass-filled Polypropylene |
| Impeller Material & Type | 3.00" Fully Enclosed Magnetic Impeller |
| Shaft Material & Seal Type | Ceramic Shaft / Seal-less Magnetic Drive |
| Maximum Flow Rate | 5.6 m³/h (1500 GPH) |
| Maximum Head / Pressure | 8.2 Meters (12 PSI) |
| Inlet / Outlet Diameter | 25.4 mm FPT / 19 mm MPT |
| Maximum Suction Lift | 0 Meters (Flooded Suction) |
| NPSHr | Data not released |
| Drive Source | Electric Motor |
| Motor/Engine Power | 0.12 kW (1/6 HP) |
| Voltage / Phase / Frequency | 115/230V / 1ph / 50/60Hz |
| Insulation Class & IP Rating | Ignition Protected, Submersible Housing |
| Self-Priming Capability | No |
| Max Liquid Temperature | 54°C (130°F) |
| Solids Handling Size | None |
| Dry Weight | 4.5 kg (10 lbs) |
| Dimensions | 210 x 135 x 150 mm |
| Marine Certifications | ABYC & USCG Standards |
