Lewmar Pro Sport 550 Windlass (Gypsy) – 1/4″ G4 1/2 Line – For Boats Up to 28 Ft., Max Pull: 550 lbs

Description

A compact horizontal gypsy-only layout gives theLewmar Pro-Sport 550a 350W 12V DC anchor rode configuration for sport fishing and runabout boats. The windlass has a stated maximum pull of 550 lbs and a 139 lbs continuous working-load rating. Its anodized marine aluminum center and stainless steel alloy components form the listed housing construction.

The gypsy accepts 1/4 in G4 chain with 1/2 in three-strand rope. A manual free-fall friction release controls the listed rode-release function, and the built-in manual override provides a separate control feature. The provided product data does not confirm an anchor, rode, switch, contactor, or circuit breaker as included.

Key Features of the Pro-Sport 550 Horizontal Windlass

• The 350W 12V DC motor powers compact horizontal anchor rode retrieval.
• The gypsy accepts 1/4 in G4 chain for confirmed chain compatibility.
• The rope section handles 1/2 in three-strand rope in the matched rode.
• The friction release provides the listed manual free-fall release function.
• The built-in manual override provides a separate stated control feature.
• The 139 lbs working-load rating identifies the continuous hauling load.
• The 550 lbs maximum pull figure states the product’s peak pull rating.
• The rated no-load speed reaches 98 ft/min without a working load.
• The windlass reaches 75 ft/min at its stated working-load rating.
• A 35A circuit breaker is required for electrical circuit protection.

Which Boats This Windlass Fits

The Pro-Sport 550 horizontal windlass is recommended for sport fishing and runabout boats up to 28 ft. Its gypsy requires 1/4 in G4 chain paired with 1/2 in three-strand rope. Boat owners should confirm both rode components match the listed dimensions because the gypsy handles the connected chain and rope sections.

the listed maximum pull is 550 lbs. The 139 lbs working-load rating provides the separate continuous hauling value. The continuous figure should guide regular retrieval assessment, while the maximum-pull figure remains a peak rating.

Materials, Technology and Use

The anodized marine aluminum center forms part of the housing, and stainless steel alloy components support the listed assembly. the listed IP67 marine deck-protection rating applies to the deck installation. The manual friction release provides the listed free-fall function, while the built-in manual override provides a separate stated control option.

Salt deposits and debris can still collect on aluminum, stainless steel components, the gypsy, and deck hardware. Regular cleaning and inspection remain necessary. The compact gypsy-only arrangement manages the specified anchor rode without a separate warping drum.

Compatibility and Installation

The Lewmar horizontal windlass fits decks from 0.8 to 1.4 in thick. The unit measures 135 mm high by 165 mm long and weighs 13 lbs. Installers should confirm the mounting area, cable route, and access to the friction release and manual override before fitting the unit.

The 12V DC circuit draws an average of 20A and requires a 35A circuit breaker. Installation planning can include onboard charging assessment alongside the listed electrical requirements. The provided product data does not confirm a switch, contactor, or circuit breaker as included.

Care and Operating Notes

Rinse the exposed housing, gypsy, chain, and rope with fresh water after saltwater exposure. Clear salt, sand, mud, and debris from the chain links, rope transition, and friction-release area before operation. Inspect the rope, chain, manual override, visible fasteners, and electrical connections before departure. Follow the manufacturer manual for lubricant selection, service intervals, disassembly, and approved replacement parts.

Warranty and Support

The Pro-Sport 550 carries a 3-year limited manufacturer warranty. The provided warranty term does not define coverage for labor, corrosion, electrical accessories, shipping, or other components. These terms reflect manufacturer-stated coverage, and buyers should verify active warranty policies directly with the seller or manufacturer prior to purchase.

Before Ordering

Confirm that your anchor rode uses 1/4 in G4 chain with 1/2 in three-strand rope. You should compare your boat with the up-to-28-ft application guide, measure deck thickness against the 0.8 to 1.4 in range, and reserve space for the 135 mm by 165 mm housing. Verify that the 12V electrical system supports the listed 20A average draw and required 35A circuit breaker. Confirm controls, circuit-protection hardware, anchor, chain, and rope with the seller because the provided product data does not confirm them as included.
