Lofrans Project 1000 Windlass – Vertical, Capstand, Chrome, 5/16″ HT/BBB – 1000W

Description

TheLofrans Project 1000combines a 1,000W 12V DC motor with a vertical deck-mounted gypsy and capstan drum. Its stated maximum pull reaches 1,984 lbs, while the continuous working-load rating is 298 lbs. The mirror-polished chrome-plated bronze housing and AISI 316 stainless steel shaft form the exposed deck assembly and drive system.

The gypsy accepts 5/16 in G4, HT, or BBB chain with 9/16 in three-strand rope. A capstan drum sits alongside the gypsy for separate line handling, and a manual friction clutch brake includes an integrated manual override. The provided product data does not confirm an anchor, rode, controls, contactor, or circuit breaker as included.

Key Features of the Project 1000 Vertical Windlass

• The 1,000W 12V DC motor powers the vertical gypsy and capstan arrangement.
• The gypsy accepts 5/16 in G4, HT, or BBB chain.
• The rope section handles 9/16 in three-strand rope within the matched rode.
• The capstan drum provides separate line handling beside the anchor rode gypsy.
• The 298 lbs working-load rating states the continuous hauling load.
• The 1,984 lbs maximum pull figure states the peak pull rating.
• The rated no-load speed reaches 75 ft/min without a working load.
• The windlass reaches 59 ft/min at its stated 298 lbs working load.
• The manual friction clutch brake includes an integrated manual override feature.
• The motor enclosure carries the listed IP66 ingress-protection rating.

Which Boats This Windlass Fits

The Project 1000 vertical windlass is recommended for power and sailboats from 33 to 43 ft. Its rope-to-chain gypsy requires 5/16 in G4, HT, or BBB chain paired with 9/16 in three-strand rope. Both components must match the listed compatibility because the gypsy handles the chain links and rope section of the same rode.

the listed 1,984 lbs maximum pull is a peak pull rating. The 298 lbs working-load rating represents the separate continuous hauling value for regular retrieval planning. These figures describe different operating conditions and should not be used interchangeably.

Materials, Technology and Use

The mirror-polished chrome-plated bronze body forms the deck housing, while the AISI 316 stainless steel shaft supports the drive assembly. the listed IP66 rating applies to the motor enclosure. The manual friction clutch brake controls the braking function, and the integrated manual override provides the listed manual-control feature.

Salt deposits, sand, and debris can still collect on chrome-plated bronze, stainless steel, the gypsy, and deck hardware. Regular cleaning and inspection remain appropriate for exposed marine components. The capstan drum handles separate line work, while the gypsy manages the matched chain and rope rode.

Compatibility and Installation

The Lofrans vertical windlass installs through deck material from 1.0 to 2.0 in thick. The deck unit measures 195 mm high with a 150 mm base diameter and weighs 39.6 lbs. Installers should confirm the available deck area and access for the vertical drive arrangement before cutting the mounting location.

The installation requires 12V DC power, a 100A circuit breaker, and capacity for the listed 110A average current draw. Before finalizing the electrical layout, installers should consider charging-system planning alongside the confirmed breaker and current requirements. The provided product data does not confirm electrical controls or circuit-protection hardware as included.

Care and Operating Notes

Rinse the exposed housing, gypsy, capstan drum, chain, and rope with fresh water after saltwater exposure. Remove salt, sand, mud, and debris from chain links, the rope section, and deck hardware before operation. Inspect the rope-to-chain transition, clutch movement, manual override access, visible fasteners, and electrical connections before departure. Follow the manufacturer manual for lubricant selection, service intervals, disassembly, and approved replacement parts.

Warranty and Support

The Project 1000 carries a 3-year limited manufacturer warranty. The provided warranty term does not define coverage for labor, corrosion, electrical accessories, shipping, or other components. These terms reflect manufacturer-stated coverage, and buyers should verify active warranty policies directly with the seller or manufacturer prior to purchase.

Before Ordering

Confirm that your anchor rode uses 5/16 in G4, HT, or BBB chain with 9/16 in three-strand rope. You should compare your boat with the 33 to 43 ft application guide, measure deck thickness against the 1.0 to 2.0 in mounting range, and allow for the 195 mm height, 150 mm base diameter, and 39.6 lbs dry weight. Check that your 12V system supports the listed 110A average draw and required 100A circuit breaker. Confirm controls, protection hardware, anchor, chain, and rope with the seller because the provided product data does not confirm them as included.
