FLIR MD-625 – Compact Static Thermal Marine Camera

Description

Add a compact fixed thermal view to a compatible helm display with the FLIR MD-625 Static Thermal Marine Camera. Its 640-class thermal sensor, 25° × 20° field of view, and 4× continuous digital zoom provide a fixed-direction thermal image for monitoring a bow approach, stern area, dockside route, or repeated channel passage. Need thermal awareness without the cost, size, or mechanical clearance of a pan-and-tilt camera? The MD-625 supports H.264 Ethernet video, analog output, 12V/24V or PoE power, and an IP67-rated fixed housing.

Key Specifications

• FLIR MD-625 compact static thermal marine camera.
• 640 × 480-class VOx microbolometer thermal camera.
• 25° × 20° fixed field of view.
• 4× continuous digital zoom.
• Analog video output and H.264 Ethernet video streaming.
• Fixed-mount design with manual tilt adjustment; no powered pan-and-tilt operation.
• Thermal display palettes include White Hot, Black Hot, Fusion, and Red Hot.
• 12V/24V DC or IEEE 802.3af PoE power support.
• Up to approximately 13W maximum power consumption.
• IP67 housing with approximate dimensions of 6 × 7 inches and weight of 3.0 lb (1.36 kg).

Integration

The MD-625 requires a compatible monitor, MFD, NVR, or IP-video viewer. Select analog video or Ethernet H.264 streaming according to the display and network configuration. It is not a chartplotter, radar, GPS unit, NMEA 2000 device, or standalone recording system.

The cited approximate detection distances—about 2,700 ft for a person and 1.2 NM for a vessel—are conditional estimates rather than guaranteed detection or recognition ranges. Thermal imagery depends on heat contrast, weather, humidity, sea state, spray, target size, range, lens condition, and mounting angle.

Installation Notes

Choose a rigid fixed deck, mast, or hardtop location with a clear view in the intended direction. Because the camera does not pan or tilt automatically, verify the field of view before drilling. Keep the lens clear of rails, rigging, exhaust, deck lights, antennas, radar shadowing, and obstructions.

Use sealed Ethernet or analog-video connections, appropriate PoE or 12V/24V power equipment, correct circuit protection, and protected cable routing. Regularly inspect the lens, mount, housing, seals, and connections after saltwater exposure.

Before Ordering

Confirm display video-input compatibility, preferred analog or H.264 Ethernet connection, PoE or 12V/24V power method, desired fixed view, field-of-view suitability, mounting location, cable route, and whether a fixed camera meets the vessel’s thermal-awareness needs.
