Raymarine Magnum 4kW Pedestal

Description

The Raymarine Magnum 4kW Pedestal radar drive unit maintains rock-solid network transmissions when commercial vessels cruise open offshore channels. Fragile maritime transmitter bases frequently suffer from severe vibration damage, causing immediate bridge display failures. Installing this dedicated heavy-duty radar transmitter core secures reliable rotation, preventing critical marine electronics from losing target data tracking during rough transit maneuvers.

This heavy duty marine mount drive core incorporates an advanced 4kW high power magnetron transmitter layout. Unlike lower-tier scanner bases that fail under continuous high-speed rotation stress, this industrial radar drive unit provides automatic dual-speed tracking adjustments. The cast aluminum pedestal shell achieves an IPX6 waterproofing standard, completely isolating internal components from saltwater spray, making the integrated digital signal processing highly effective over long coastal transits.

Key Features of Raymarine Magnum 4kW Pedestal

• The integrated high-torque motor driver provides automated 24 RPM and 48 RPM rotation speed control. This smart configuration adapts automatically to short-range tracking needs or long-distance target updates safely.
• The connection array features a single RayNet connection port terminal embedded in the base. These clean network lines eliminate communication latency, ensuring immediate data streaming to Axiom multi-function screens.
• The heavy-duty transmitter core is explicitly engineered to interface with either 4-foot or 6-foot open array antennas. This flexible scanner compatibility allows custom builders to scale their physical radar profile easily.
• This rugged physical pedestal profile results in an exceptionally rigid installation weighing 41.4 lbs, shielding the primary 4kW processing boards from intense high-frequency hull vibrations across continuous operations safely.

Why Choose This Radar over Generic Alternatives

Upgrading to the genuine Raymarine Magnum 4kW Pedestal base unit is essential for expanding long-range vessel radar tracking layers. Unlike low-power closed domes that lose small targets in heavy clutter, this high-output 4kW driver core forces signals through severe coastal squalls. It perfectly coordinates target positions across standard marine bridges, avoiding expensive hardware replacements over years of intense service.

Application & Limitations

This radar drive and transmitter unit performs outstandingly on commercial coastal craft, multi-deck luxury motor yachts, and blue-water sportfishing vessels hulls. However, because it operates strictly as a pedestal base unit, it cannot function without an external 4ft or 6ft open array antenna attachment. Additionally, its substantial 41.4 lbs dry weight requires a structurally reinforced master mast mounting structure during rough transit lines.

Technical Specifications

To assist professional marine electronics installers, custom boat builders, and commercial vessel captains in verifying exact onboard extended local network bridge integration parameters prior to purchase, the comprehensive engineering data breakdown outlined below provides the official manufacturer measurements, electrical metrics, and environmental ratings for this specialized raymarine magnum specs hardware array. Reviewing these physical limits ensures proper installation.

• Brand & Model Name: Raymarine | Magnum 4kW Radar Pedestal | MPN: E70484
• Technology Category: Radar Drive & Transmitter Unit platform
• Scanner Compatibility Profile: Fully optimized for 4ft or 6ft Magnum Open Array Antennas
• Peak Power Output: Reliable 4kW peak pulse transmitter drive core
• Antenna Rotation Speed: 24 RPM / 48 RPM automatic speed selection matching tracking needs
• Data Interface Matrix: 1x RayNet Connection port terminal for high-speed display linking
• Voltage Input Rail: Fully compatible with standard 12V / 24V DC marine electrical systems
• Power Draw Load: 70 Watts maximum active transmission electricity consumption draw
• Physical Profile & Protection: IPX6 rated high-pressure weather and sea spray waterproofing protection
• Physical Weight Sizing: 41.4 lbs (18.8 kg) net dry pedestal weight backed by a 2-Year Standard Warranty
