Furuno FAR1513 – 12kW 96nm Black Box Radar System (Less Antenna)
This Furuno FAR1513 – 12kW 96nm Black Box Radar System (Less Antenna) has a dry weight of 7.0 kg (Processor Unit).
- Antenna Type: Requires Open Array (X-Band).
- Antenna Size: 4ft / 6ft / 8ft Options.
- Peak Power Output: 12kW.
- Maximum Range: 96 Nautical Miles.
- Horizontal Beamwidth: Dependent on Antenna (1.9° to 0.95°).
$9,900.00
Products are almost sold out
This product is about to run out
available only:
3In Stock
| Radar Type | High-Resolution Magnetron (Black Box) |
| Antenna Type | Requires Open Array (X-Band) |
| Antenna Size | 4ft / 6ft / 8ft Options |
| Peak Power Output | 12kW |
| Maximum Range | 96 Nautical Miles |
| Horizontal Beamwidth | Dependent on Antenna (1.9° to 0.95°) |
| Vertical Beamwidth | 20° |
| Rotation Speed | 24 / 48 RPM |
| Pulse Width | 0.07 to 1.2 μs |
| Target Tracking (MARPA/ARPA) | TT (Up to 50 targets), AIS (Up to 300) |
| Doppler Technology | No |
| Dual Range Support | Yes |
| Minimum Range | 25 meters |
| Receiver Noise Figure | 6 dB |
| Operating Voltage | 12V / 24V DC |
| Power Consumption (Operating) | 100W (Max) |
| Power Consumption (Standby) | 35W |
| Data Connectivity | Ethernet, 3x NMEA 0183, AD-10 |
| Waterproof Rating | IP20 (Processor) / IP56 (Gearbox) |
| Wind Velocity Rating | 100 Knots |
| Weight | 7.0 kg (Processor Unit) |
| Warranty | 2 Years |
